Scanic

Modern Document Scanner for the Web

Scanic is a blazing-fast, lightweight, and modern document scanner library written in JavaScript and rust (WASM). It enables developers to detect, scan, and process documents from images directly in the browser or Node.js, with no dependencies or external services.

Why Scanic?

I always wanted to use document scanning features within web environments for years. While OpenCV makes this easy, it comes at the cost of a 30+ MB download.

Scanic combines pure JavaScript algorithms with Rust-compiled WebAssembly for performance-critical operations like Gaussian blur, Canny edge detection, and gradient calculations. This hybrid approach delivers near-native performance while maintaining JavaScript’s accessibility and a lightweight footprint.

Performance-wise, I’m working to match OpenCV solutions while maintaining the lightweight footprint - this is an ongoing area of improvement.

This library is heavily inspired by jscanify

Features

Demo

Try the live demo: Open Demo

Installation

npm install scanic

Or use via CDN:

<script src="https://unpkg.com/scanic/dist/scanic.js"></script>

Usage

import { scanDocument, extractDocument } from 'scanic';

// Simple usage - just detect document
const result = await scanDocument(imageElement);
if (result.success) {
  console.log('Document found at corners:', result.corners);
}

// Extract the document (with perspective correction)
const extracted = await scanDocument(imageElement, { mode: 'extract' });
if (extracted.success) {
  document.body.appendChild(extracted.output); // Display extracted document
}

// Manual extraction with custom corner points (for image editors)
const corners = {
  topLeft: { x: 100, y: 50 },
  topRight: { x: 400, y: 60 },
  bottomRight: { x: 390, y: 300 },
  bottomLeft: { x: 110, y: 290 }
};
const manualExtract = await extractDocument(imageElement, corners);
if (manualExtract.success) {
  document.body.appendChild(manualExtract.output);
}

Complete Example

import { scanDocument } from 'scanic';

async function processDocument() {
  // Get image from file input or any source
  const imageFile = document.getElementById('fileInput').files[0];
  const img = new Image();

  img.onload = async () => {
    try {
      // Extract and display the scanned document
      const result = await scanDocument(img, {
        mode: 'extract',
        output: 'canvas'
      });

      if (result.success) {
        // Add the extracted document to the page
        document.getElementById('output').appendChild(result.output);

        // Or get as data URL for download/display
        const dataUrl = result.output.toDataURL('image/png');
        console.log('Extracted document as data URL:', dataUrl);
      }
    } catch (error) {
      console.error('Error processing document:', error);
    }
  };

  img.src = URL.createObjectURL(imageFile);
}

// HTML setup
// <input type="file" id="fileInput" accept="image/*" onchange="processDocument()">
// <div id="output"></div>

API Reference

Core Functions

scanDocument(image, options?)

Main entry point for document scanning with flexible modes and output options.

Parameters:

Returns: Promise<{ output, corners, contour, debug, success, message }>

Examples

const options = {
  mode: 'extract',
  maxProcessingDimension: 1000,  // Higher quality, slower processing
  lowThreshold: 50,              // More sensitive edge detection
  highThreshold: 150,
  dilationKernelSize: 5,         // Larger dilation kernel
  minArea: 2000,                 // Larger minimum document area
  debug: true                    // Enable debug information
};

const result = await scanDocument(imageElement, options);

Different Modes and Output Formats

// Just detect (no image processing)
const detection = await scanDocument(imageElement, { mode: 'detect' });

// Extract as canvas
const extracted = await scanDocument(imageElement, {
  mode: 'extract',
  output: 'canvas'
});

// Extract as ImageData
const rawData = await scanDocument(imageElement, {
  mode: 'extract',
  output: 'imagedata'
});

// Extract as DataURI
const rawData = await scanDocument(imageElement, {
  mode: 'extract',
  output: 'dataurl'
});

Framework Examples

👉 Vue.js Example & Guide

👉 React Example & Guide

Development

Clone the repository and set up the development environment:

git clone https://github.com/marquaye/scanic.git
cd scanic
npm install

Start the development server:

npm run dev

Build for production:

npm run build

The built files will be available in the dist/ directory.

Building the WebAssembly Module

The Rust WASM module is pre-compiled and included in the repository. If you need to rebuild it:

npm run build:wasm

This uses Docker to build the WASM module without requiring local Rust installation.

Performance Architecture

Scanic uses a hybrid JavaScript + WebAssembly approach:

Contributing

Contributions are welcome! Here’s how you can help:

  1. Report Issues: Found a bug? Open an issue with details and reproduction steps
  2. Feature Requests: Have an idea? Create an issue to discuss it
  3. Pull Requests: Ready to contribute code?
    • Fork the repository
    • Create a feature branch (git checkout -b feature/amazing-feature)
    • Commit your changes (git commit -m 'Add amazing feature')
    • Push to the branch (git push origin feature/amazing-feature)
    • Open a Pull Request

Please ensure your code follows the existing style.

💖 Sponsors

Special thanks to our amazing sponsors who make this project possible!

### 🏆 Gold Sponsors

ZeugnisProfi
Professional certificate and document services
ZeugnisProfi.de
German document processing specialists
Verlingo
Language and translation services

Roadmap

License

MIT License © marquaye
